HP Compaq 6735b User Manual

Eco Data Eco-Label Certifications This product has received or is in the process of being certified to the following
approvals and may be labeled with one or more of these marks:
US Energy Star
Taiwan Green Mark
IT ECO declaration
EPEAT – GOLD
System Configuration The configuration used for the Energy Consumption and Declared Noise
Emissions data for the Convertible Mini tower Desktop model is based on a
"Typically Configured Notebook"
Energy Consumption 115 VAC 230 VAC 100 VAC
Normal Operation 13.44 W 13.55 W 13.20 W
Sleep (Energy Star low
power mode)
1.61 W 1.61 W 1.58 W
Off 0.511 W 0.541 W 0.512 W
Heat Dissipation* 115 VAC 230 VAC 100 VAC
Normal Operation 46 BTU/hr 46 BTU/hr 45 BTU/hr
Sleep 6 BTU/hr 6 BTU/hr 5 BTU/hr
Off 2 BTU/hr 2 BTU/hr 2 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming the
service level is attained for one hour.
This product is in compliance with US executive order 13221, WOL (wake on
LAN) disabled.
Declared Noise Emissions
(in accordance with
ISO 7779 and ISO 9296)
Sound Power
(LWAd, bels)
Sound Pressure
(LpAm, decibels)
Idle 3.4 27
Operation 3.6 29
Batteries This product complies with ISO standards:
EU Directive 91/ 157/ EEC
EU Directive 93/ 86/ EEC
EU Directive 98/ 101/ EEC
Batteries used in the product do not contain:
Mercury greater than 5ppm by weight
Cadmium greater than 10ppm by weight
Lead greater than 4000 ppm by weight.
The battery type and chemistry used in the product is:
QuickSpecs
HP Compaq 6735b Notebook PC
Technical Specifications
DA - 13055 North America — Version 24 — June 17, 2010 Page 36

HP Compaq 6735b Specifications

General

Processor cache	1 MB
Processor frequency	2.1 GHz
Processor cache type	L2
Motherboard chipset	AMD M780G
HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Card reader integrated	No
Total storage capacity	160 GB
Display diagonal	15.4 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Type	PC
LightScribe	Yes
Modem speed	56 Kbit/s
Wireless technology	802.11a/b/g/n
Memory slots	2x SO-DIMM
Internal memory	2 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 2 GB
Audio system	HD Audio
Number of built-in speakers	2
Networking features	Gigabit Ethernet, WLAN
Operating system installed	Windows Vista Business
Number of battery cells	6
TV-out type	S-Video
Charging port type	DC-in jack
USB 2.0 ports quantity	4
Parallel ports quantity	0
Cable lock slot type	Kensington
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Non-operating relative humidity (non-condensing)	10 - 90 %
AC adapter power	90 W
Discrete graphics card model	AMD Radeon HD 3200
Country of origin	China

Weight and Dimensions

Depth	265 mm
Width	356 mm
Height	33 mm
Weight	2700 g
