HP Compaq 6735b User Manual

Interfaces ExpressCard/54 slot One (or optional Smart Card Reader)
External monitor One (VGA)
1394a One
Stereo microphone in One
Stereo headphone/line
out
One
Power connector One
RJ-11/modem One
RJ-45/Ethernet One
S-video TV out One (Support for NTSC/PAL)
USB 2.0 Four
Serial port One
Docking connector One
Secondary battery
connector
One
Audio/Visual High Definition Audio support w/24-bit DAC
Integrated stereo speakers
Integrated microphone (dual-microphone array when equipped with optional VGA webcam)
Touch-sensitive controls for volume up, volume down, and mute
Stereo headphone/line out
Stereo microphone in
Optional VGA webcam
Supports videoconferencing and still image capture
Large image sensor for excellent color matching and good low light sensitivity
Up to 30 frames/sec
Fixed focus lens
Video capture up to 640x480 pixels
16-bit true color (camera sensors output YCrCb format among others)
QuickSpecs
HP Compaq 6735b Notebook PC
Standard Features
DA - 13055 North America — Version 24 — June 17, 2010 Page 9

HP Compaq 6735b Specifications

General

Processor cache	1 MB
Processor frequency	2.1 GHz
Processor cache type	L2
Motherboard chipset	AMD M780G
HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Card reader integrated	No
Total storage capacity	160 GB
Display diagonal	15.4 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Type	PC
LightScribe	Yes
Modem speed	56 Kbit/s
Wireless technology	802.11a/b/g/n
Memory slots	2x SO-DIMM
Internal memory	2 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 2 GB
Audio system	HD Audio
Number of built-in speakers	2
Networking features	Gigabit Ethernet, WLAN
Operating system installed	Windows Vista Business
Number of battery cells	6
TV-out type	S-Video
Charging port type	DC-in jack
USB 2.0 ports quantity	4
Parallel ports quantity	0
Cable lock slot type	Kensington
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Non-operating relative humidity (non-condensing)	10 - 90 %
AC adapter power	90 W
Discrete graphics card model	AMD Radeon HD 3200
Country of origin	China

Weight and Dimensions

Depth	265 mm
Width	356 mm
Height	33 mm
Weight	2700 g
