HP Compaq 6735s Specifications

Keyboard
KeyboardKeyboard
Keyboard The 101/102-key compatible keyboard features an industry standard, full-pitch key layout with desktop
keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both left and right
control and alt keys, and 12 function keys. U.S. and International key layouts are available. Other
features include an integrated numeric keypad, hotkeys for instant access to power conservation,
brightness, and other features, 19 mm x 19 mm key pitch (center-to-center spacing), 2.5 mm stroke, and
comfort-dished keycaps.
Pointing device
Pointing devicePointing device
Pointing device Touchpad with scroll zone, two pick buttons
Expansion card slots
Expansion card slotsExpansion card slots
Expansion card slots
ExpressCard/54 slot
ExpressCard/54 slotExpressCard/54 slot
ExpressCard/54 slot Supports ExpressCard/54 (54 mm x 75 mm x 5 mm) and ExpressCard/34
(34 mm x 75 mm x 5 mm) card sizes
Media Card Reader
Media Card ReaderMedia Card Reader
Media Card Reader Supports SD (Secure Digital), MMC (MultiMedia Card), Memory Stick,
Memory Stick Pro, Memory Stick Duo*, xD-Picture card
* Memory Stick Duo Adapters are required and sold separately. Inserting a Memory Stick Duo Card
directly into your notebook could damage the memory card and/or notebook.
Storage
StorageStorage
Storage Internal Storage Device
Internal Storage DeviceInternal Storage Device
Internal Storage Device 120/160/250/320 GB 5400 rpm SMART SATA II Hard Drive
NOTE:
NOTE:NOTE:
NOTE: These hard drives are customer removable and will withstand multiple insertion/removal cycles.
Up to 10 GB is reserved for the system recovery software.
HP 3D DriveGuard
HP 3D DriveGuardHP 3D DriveGuard
HP 3D DriveGuard The hard drive is mounted directly to the notebook frame, reducing the
transmission of shock to the hard drive. Uses three-axis digital motion
detection with intelligent sensitivity to help protect the hard drive during
normal use from shock and vibration. The digital accelerometer temporarily
halts all data transfer and parks the hard drive when abrupt motion is
detected.
Fixed optical drive
Fixed optical driveFixed optical drive
Fixed optical drive DVD+/-RW SuperMulti DL LightScribe Drive
DVD/CD-RW Combo Drive
Interfaces
InterfacesInterfaces
Interfaces ExpressCard/54 slot
ExpressCard/54 slotExpressCard/54 slot
ExpressCard/54 slot One (Supports ExpressCard/54 and ExpressCard/34)
External monitor
External monitorExternal monitor
External monitor One (VGA)
Stereo microphone in
Stereo microphone inStereo microphone in
Stereo microphone in One
Stereo headphone/line
Stereo headphone/lineStereo headphone/line
Stereo headphone/line
out
outout
out
One
Power connector
Power connectorPower connector
Power connector One
RJ-11/modem
RJ-11/modemRJ-11/modem
RJ-11/modem One
RJ-45/Ethernet
RJ-45/EthernetRJ-45/Ethernet
RJ-45/Ethernet One
USB 2.0
USB 2.0USB 2.0
USB 2.0 Four
LED status indicators
LED status indicatorsLED status indicators
LED status indicators Seven
QuickSpecs
HP Compaq 6735s Notebook PC
HP Compaq 6735s Notebook PCHP Compaq 6735s Notebook PC
HP Compaq 6735s Notebook PC
Standard Features
DA - 13064 North America — Version 10 — December 15, 2008 Page 5

HP Compaq 6735s Specifications

General

Graphics	ATI Radeon HD 3200
Operating System	Windows Vista Business
Processor	AMD Turion X2
Display	15.4-inch WXGA (1280 x 800)
Memory	Up to 8 GB DDR2 800 MHz
Storage	160GB
Optical Drive	DVD+/-RW SuperMulti DL LightScribe
Networking	802.11a/b/g/n, Bluetooth 2.0, Gigabit Ethernet
Audio	headphone/line out, microphone in
Ports	3 USB 2.0, VGA, microphone in, headphone/line out, RJ-45
Battery	6-cell Lithium-Ion
