HP Compaq 6735s User Manual

8-Cell (63 WHr) Li-Ion
battery
Dimensions (H x W x L) 0.8 x 1.9 x 10.6 in (2.0 x 4.8 x 27.0 cm)
Weight 0.980 lb (0.445 kg)
Cells/Type 8-cell Li-Ion
Energy Watt-hour Capacity 63 WHr
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 140° F (–10° to 60° C)
Non-operating –4° to 140° F (–20° to 60° C)
Battery Re-Charge Time System in OFF mode or
Standby
2.5 hours
System ON 3 to 5 hours (depending on system power
consumption)
HP Fast Charge Technology Charges the battery up to 90% within 1.5 hours
when system is OFF
6-Cell (47 WHr) Li-Ion
battery
Dimensions (H x W x L) 0.8 x 2.1 x 8.0 in (2.0 x 5.3 x 20.3 cm)
Weight 0.690 lb (0.313 kg)
Cells/Type 6-cell Li-Ion
Energy Watt-hour Capacity 47 WHr
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 140° F (–10° to 60° C)
Non-operating –4° to 140° F (–20° to 60° C)
Battery Re-Charge Time System in OFF mode or
Standby
2.5 hours
System ON 3 to 5 hours (depending on system power
consumption)
HP Fast Charge Technology Charges the battery up to 90% within 90 minutes
when system is OFF
Displays
QuickSpecs
HP Compaq 6735s Notebook PC
Technical Specifications
DA - 13064 North America — Version 17 — June 30, 2009 Page 16

HP Compaq 6735s Specifications

General

Graphics	ATI Radeon HD 3200
Operating System	Windows Vista Business
Processor	AMD Turion X2
Display	15.4-inch WXGA (1280 x 800)
Memory	Up to 8 GB DDR2 800 MHz
Storage	160GB
Optical Drive	DVD+/-RW SuperMulti DL LightScribe
Networking	802.11a/b/g/n, Bluetooth 2.0, Gigabit Ethernet
Audio	headphone/line out, microphone in
Ports	3 USB 2.0, VGA, microphone in, headphone/line out, RJ-45
Battery	6-cell Lithium-Ion
