For accessibility information on HP products, please visit
http://www.hp.com/accessibility
.
* This device is not intended for use at visual display workplace in compliance with BildscharbV. If this
product is used in an Office Environment where the VDU Directive 90/270/EEC is applicable
(Bildschirmarbeitsverordnung), an external monitor and external keyboard are recommended to avoid
potential reflections.
HP 90W Smart AC Adapter
Dimensions
5.24 x 2.28 x 1.1 in (13.3 x 5.8 x 2.9 cm)
Weight
0.86 lb (390 g)
Input
100 to 240 VAC
Input Efficiency
83% min at 115 VAC
Input frequency range
47 to 63 Hz
Input AC current
1.5 A at 90 VAC, 0.75 A at 180 VAC PFC Version
2.4 A at 90 VAC, 1.2 A at 180 VAC NON PFC Version
Output
Output power
90W
DC output
18.5V
Hold-up time
5 msec at 115 VAC input
Output current limit
<11A, Over voltage protection- 29V max
automatic shutdown
Connector
3 pin/grounded, mates with interchangeable cords
Environmental Design
Operating temperature
32° to 104° F (0° to 40° C)
Non-operating (storage)
temperature
–4° to 149° F (–20° to 65° C)
Altitude
0 to 10,000 ft (0 to 3,048 m)
Humidity
20% to 80%
Storage Humidity
10% to 90%
EMI and Safety
Certifications
CE Mark – full compliance with LVD and EMC directives; Worldwide safety
standards – IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals –
C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B,
CCC, NOM-1 NYCE; MTBF- over 200,000 hours at 25°C ambient condition.
QuickSpecs
HP Compaq 6820s Notebook PC
Technical Specifications
DA - 12768 EMEA — Version 11 — May 8, 2008
Page 12
