HP Compaq 8710w

HP 135W Smart AC
Adapter
Dimensions 6.65 x 2.56 x 1.5 in (16.9 x 6.5 x 3.8 cm)
Weight 1.54 lb (700 g)
Input 100 to 240 VAC
Input Efficiency 83% min at 115 VAC
Input frequency range 47 to 63 Hz
Input AC current 2.2 A at 90 VAC, 1.1 A at 180 VAC NON PFC Version
Output Output power 65W 135W
DC output 19.0V
Hold-up time 5 msec at 115 VAC input
Output current limit <18A, Over voltage protection- 29V max
automatic shutdown
Connector 3 pin/grounded, mates with interchangeable cords
Environmental Design Operating temperature 32° to 95° F (0° to 35° C)
Non-operating (storage)
temperature
-4° to 149° F (-20° to 65° C)
Altitude 0 to 10,000 ft (0 to 3,048 m)
Humidity 20% to 80%
Storage Humidity 10% to 90%
EMI and Safety
Certifications
CE Mark - full compliance with LVD and EMC directives; Worldwide safety
standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals -
C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B,
CCC, NOM-1 NYCE; MTBF - over 200,000 hours at 25°C ambient condition.
Option Kit Contents 135W AC Adapter, power cable, warranty booklet
Optional HP Ultra-
Capacity Battery
Dimensions (H x W x L) 1.3 x 6.0 x 10.6 in (3.33 x 15.25 x 26.88 cm)
Weight 1.77 lb (0.803 kg)
Cells/Type 12-cell Lithium-Ion
Energy Watt-hour Capacity 95Wh
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 140° F (–10° to 60° C)
Non-operating –4° to 140° F (–20° to 60° C)
Battery Re-Charge Time Smart Adapter 3 to 4 hours
System ON 4 to 5 hours (depending on system power
consumption)
Fuel Gauge When pressed, LEDs light indicating level of charge remaining on battery
QuickSpecs
HP Compaq 8710w Mobile Workstation
Technical Specifications
DA - 12731 North America — Version 17 — July 14, 2008 Page 24
