HP Compaq Business Desktop dx2000 uT Series

HP-00007-01, Appendix 3 30-June-2005
HP Restricted
Page 6
FIGURE 13: Tie wrap to cut FIGURE 14: Power supply PCA screws
FIGURE 15: Inlet and Switch screws FIGURE 16: Tie wraps to cut
FIGURE 17: Grounding screw FIGURE 18: PFC cables – cut location
