HP ADD2 SDVO PCIe x16
DVI-D Adapter
Models HP ADD2 SDVO DVI-D Out Adapter
Form Factor Low-profile card
DVI-D Connector Digital connection only
Dual Head Support Yes, when used with the integrated VGA connector
Display Devices
Supported
HP L1740
HP L1940T
HP L2045W
HP LP1965
NOTE: These graphics adapters offer optimal performance with any display that meets applicable VESA
standards.
Color Depth All modes support 8-bpp, 16-bpp, and 24-bpp color depths
Host Interface Connector Mechanically compliant with PCI-E standard
Complies with the Intel ADD2 and Intel Serial Digital Video Output (SDVO)
specifications
Dot Clock 165 MHz maximum
Display Modes Supports display modes that require up to 165-MHz bandwidth on the link, as
shown in the following table.
Resolution 60-Hz LCD 60-Hz 75-Hz 85-Hz
Blanking 5% reduced GTF GTF GTF
640 x 480 VGA Yes Yes Yes Yes
800 x 600 SVGA Yes Yes Yes Yes
1024 x 768 XGA Yes Yes Yes Yes
1280 x 1024 SXGA Yes Yes No No
1600 x 1200 UXGA Yes Yes No No
HP DisplayPort to VGA
Adapter
Connectors DisplayPort and VGA connector
Adapter length 8 in (20 cm)
Adapter weight .1 lbs (.06 kg)
Option kit contents HP DisplayPort to VGA Adapter, documentation
Maximum vertical refresh
rate
85 Hz
Display support 162 MHz RAMDAC
Display max resolution 1600x1200
QuickSpecs
HP Compaq dx2390 Microtower Business PC
Technical Specifications - Graphics
DA - 12990 Worldwide — Version 11 — July 28, 2009 Page 30

HP Compaq dx2390 Specifications
