HP Compaq dx2400 Quickspecs

Unit Environment and
Operating Conditions
General Unit Operating Guidelines
Keep the computer away from excessive moisture, direct moisture and the extremes of heat and
cold, to ensure that unit is operated within the specified operating range.
Leave a 4 in (10.2 cm) clearance on all vented sides of the computer to permit the required airflow.
Never restrict airflow into the computer by blocking any vents or air intakes.
Do not stack computers on top of each other or place computers so near each other that they are
subject to each other's re-circulated or preheated air.
Occasionally clean the air vents on the front, back, and any other vented side of the computer. Lint,
dust and other foreign matter can block the vents and limit the airflow.
If the computer is to be operated within a separate enclosure, intake and exhaust ventilation must
be provided on the enclosure, and the same operating guidelines listed above will still apply.
Temperature Range Operating 50° to 95° F (10° to 35° C)
Non-operating -22° to 140° F (-30° to 60° C)
Relative Humidity Operating 10% to 90% (non-condensing at ambient)
Non-operating 5% to 95% (non-condensing at ambient)
Maximum Altitude
(unpressurized)
Operating 10,000 ft (3048 m)
Non-operating 30,000 ft (9000 m)
NOTE: Operating temperature is de-rated 1.0 deg C per 1000 ft (300 m) to 10,000 ft (3000 m) above sea
level, no direct sustained sunlight. Maximum rate of change is 10 deg C/Hr. The upper limit may be limited
by the type and number of options installed.
System Board Processor Socket T; LGA775 industry standard Micro ATX form factor
Support single Intel Core 2 Duo or Quad, Celeron 4xx or Dual Core
PWM ON NCP5387 – 3 phase
Chipset Intel G33 Express
Intel I/O Controller Hub 9 (ICH9)
Super I/O ASUS F8000
Front Side Bus Frequency 800/1066/1333 MHz
Memory DDR2 SDRAM
4 x DIMM slots
Clock Generator IDT CV1908PAG
Integrated Graphics Intel Graphics Media Accelerator (GMA) 3100
Audio Realtek ALC888S HD Audio compatible codec with two channel audio 3D audio
LOM Realtek RTL8111C-GR GbE Ethernet controller
Storage Four Serial ATA interfaces
Expansion Slots 1 x PCI 2.3 slot
2 x PCI Express x1 slots
1 x PCI Express x16 slot
BIOS SPI EEPROM
Industrial Standard PCI 2.3 compliant
USB 2.0
QuickSpecs
HP Compaq dx2400 Microtower Business PC
System Details
DA - 12921 North America — Version 25 — July 28, 2009 Page 9

HP Compaq dx2400 Specifications

General

Tcase	74.1 °C
Bus type	FSB
Stepping	M0
Processor cache	2 MB
Processor cores	2
Processor model	E5200
System bus rate	- GT/s
Processor family	Intel® Pentium®
Processor series	Intel Pentium E5000 Series for Desktop
Processor socket	LGA 775 (Socket T)
Processor codename	Wolfdale
Processing Die size	82 mm²
Processor frequency	2.5 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	12.5
Number of Processing Die Transistors	228 M
Audio system	HD
Product type	PC
Motherboard chipset	Intel® G33
Memory slots	4x DIMM
Internal memory	1 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	- GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD interface	SATA II
Optical drive type	DVD Super Multi
Total storage capacity	250 GB
LightScribe	Yes
Networking features	Gigabit Ethernet
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Discrete graphics card model	Intel® GMA 3100
Operating system installed	Windows Vista Business
Compatible operating systems	Windows XP Windows Vista
Optional operating system supplied	Windows XP Professional
Serial ports quantity	-
USB 2.0 ports quantity	6
Firewire (IEEE 1394) ports	0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Chassis type	Micro Tower
Product color	Black, Silver
Country of origin	China
Cable lock slot type	Kensington
Number of 3.5\" bays	3
Non-operating altitude	0 - 9144 m
Operating temperature (T-T)	10 - 35 °C
Power supply input voltage	90 - 240 V
Power consumption (typical)	300 W
Power supply input frequency	50 - 60 Hz
Processor ARK ID	37212
Processor package size	37.5 x 37.5 mm

Weight and Dimensions

Depth	373 mm
Width	180 mm
Height	365 mm
Weight	10200 g
