A9S75AA
TN (Twisted Nematic) LED Backlit LCD
(19 in) diagonally measured
Up to 170° horizontal/160° vertical (10:1 minimum contrast ratio)
250 nits (cd/m
)
1000:1 (typical); 1,000,000:1 (dynamic)
5 ms (on/off)
Horizontal: 24 to 83 kHz; Vertical: 50 to 76 Hz
1280 x 1024 @ 60 Hz
1280 x 1024 @ 60 Hz, 1280 x 960 @ 60 Hz, 1280 x 800 @ 60 Hz, 1280 x 720 @ 60 Hz, 1024 x 768 @ 60 Hz, 800 x 600 @
60 Hz, 640 x 480 @ 60 Hz
Three connectors: (1) 15-pin mini D-sub analog VGA (cable included) and (1) DVI-D (cable included in select regions),
(1) Display Port (cable included in select regions)
display)
Size and positioning, contrast, brightness, clock, clock phase, selectable color temperature, serial number, mode
displayed, sleep timer, input selection, factory reset, individual color contrast, full-screen resolution
Auto-Sensing, (90 to 265 VAC)
Maximum: 35 watts; Typical: 27 watts ; Power saving: <0.5 watts standby; <.0.5 watts off
Unpacked w/stand: 41,7x 36,6 to 48,6 x 19,2 cm (16.4 x 14.4 to 19.1 x 7.5 in)
Head only: 41,7 x 4,7 x 34,7 cm (16.4 x 1.8 x 13.6 in)
5° to + 25° vertical; Swivel: ± 180° horizontal; Pivot: 90° into portrait orientation; Height:
range
HP LCD Speaker Bar—Part number NQ576AA: Powered directly by the connected PC, the Speaker Bar seamlessly
attaches to the monitor's lower bezel to bring full audio support to select HP flat panel monitors. Features include dual
speakers with full sound range and dual external headphone jacks. Sold separately. For more information, refer to the
product’s QuickSpecs.
HP LCD Monitor Quick Release—Part number EM870AA: An easy-to-use, VESA-compliant, LCD monitor mounting
solution that allows you to quickly and securely attach an LCD monitor to a variety of stands, brackets, arms or wall
mounts. For more information, refer to this product's QuickSpecs document.
HP USB Graphics Adapter—Part number NL571AA: Enables connection of up to six simultaneous displays to help you
boost productivity and multi-task across several open applications. Use one Adapter to bridge between a notebook or
desktop PC and second monitor or use multiple Adapters to connect several displays to each other.
HP Business PC Security Lock Kit—Part number PV606A: Attaches to the rear of the PC with a six-foot steel cable that
can be used to secure a PC or peripherals such as mice, keyboards, monitors or USB security devices to protect them
against unauthorized removal by physically connecting the system to an anchor point.
compliance
TCO 5.0 Displays, ISO 9241-307, CISPR Requirements, VCCI Approvals, KC and KCC (Korean) Requirements, CSA 60950-
UL 60950-1, EN55022 Class B, CNS 13438 Class B, IEC 60950-1, China Energy Label (CEL), China MEPS, Korea MEPS
(pending, Energy Boy), SmartWay – NA only - Energy logistics, EUP Lot 6 Tier 1 AS/NZS 3548 Class B Approval, “GS”
Mark, TUV Approvals, GEEA, CE Marking, FCC Part 15 class B Approval, ENERGY STAR® qualified, EN55024 Class B,
EN60950 -1, CUL, CCIB, CCEE, IT ECO (EDS), EPEAT® Gold (select regions)
5
Protected by HP, including a 3 years parts, 3 years labor, and 3 years onsite service (3/3/3) standard limited warranty.
Optional Care Pack Services are extended service contracts which go beyond your standard warranties.
1. Internet access required and sold separately.
2. Optional accessories sold separately.
3 HP Care Pack Services extend service contracts beyond the standard warranties. Service levels and response times for HP Care Packs may vary depending on your
geographic location. Service starts from date of hardware purchase. To choose the right level of service for your HP product, use the HP Care Pack Services Lookup
Tool at www.hp.com/go/lookuptool. Additional HP Care Pack Services information by product is available at www.hp.com/hps/carepack.
4. All specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or lower.
5. EPEAT® Gold where HP registers commercial display products. See www.epeat.net for registration status in your country.
HP Compaq LA1956x 19-inch LED Backlit Monitor
© 2012 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products
and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an
additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. ENERGY STAR is a registered mark owned by the U.S.
government. To learn more, visit http://www.hp.com. May 2012
