Right door (optional paper feeder)
1. Open the right door.
Figure 6-38 Remove the right door; optional paper feeder (1 of 3)
2. Release one tab (callout 1), and then slide the stopper toward the right side of the product to remove
it.
Figure 6-39 Remove the right door; optional paper feeder (2 of 3)
1
190 Chapter 6 Removal and replacement ENWW
