7. Remove ten screws (callout 9), and then carefully remove the assembly.
CAUTION: Be careful when you remove the assembly. The cams on the backside of the
assembly can be dislodged. If the cams become dislodged, install them on the shafts as shown in
Figure 6-201 Reinstall the main-drive assembly (2 of 11) on page 292.
The black cam must be installed on the shaft furthest away from the developing-disengagement
motor. The white cams are interchangeable.
Figure 6-199 Remove the main-drive assembly (7 of 7)
9
ENWW Internal assemblies 291
