HP embedded Jetdirect page
The second configuration page is the HP embedded Jetdirect page, which contains the following
information:
Figure 7-47 HP embedded Jetdirect page
HP Color LaserJet CP 3525 Printers
Embedded Jetdirect Page
Page 1
2
3
1
4
5
6
1 HP Jetdirect Configuration indicates the product status, model number, hardware firmware version, port select, port
configuration, auto negotiation, manufacturing identification, and manufactured date.
2 Security Settings information
3 Network Statistics indicates the total packets received, unicast packets received, bad packets received, framing errors
received, total packets transmitted, unsendable packets, transmit collisions, and transmit late collisions.
4 TCP/IP information, including the IP address
5 IPv4 information
6 IPv6 information
Always make sure the status line under the HP Jetdirect configuration lines indicates "I/O Card Ready".
366 Chapter 7 Solve problems ENWW
