Table 8-4 Internal components (1 of 5)
Ref Description Part number Qty
1 Lifter cable assembly RM1-5742-000CN 1
3 Cover, front inner lower RL1-1914-000CN 1
5 Cover, front inner upper RC2-5006-000CN 1
6 Cover, front inner lower RL1-1915-000CN 1
8 Cover, left lower RC2-5069-000CN 1
12 Waste toner detect assembly RM1-5696-000CN 1
13 Waste toner duct assembly RM1-4977-000CN 1
14 Toner collection unit kit CC468-67910 1
17 Spring, tension RU6-2236-000CN 4
18 Spring, ground RU6-2237-000CN 4
19 Lever, cartridge pressure front RC2-3983-000CN 4
21 Seal, waste toner box RC2-4780-000CN 1
24 Lock, door RC2-5937-000CN 1
26 Lever, box presence detect RC2-5951-000CN 1
27 Spring, compression RU6-2568-000CN 1
ENWW Internal components 459
