Table 8-6 Internal components (3 of 5)
Ref Description Part number Qty
6 Link, door stopper right RC2-4916-000CN 1
9 Cover, right lower inner RC2-5019-000CN 1
10 Interlock link RC2-5120-000CN 1
11 Interlock switch mount RC2-5123-000CN 1
12 Interlock link switch arm RC2-5121-000CN 1
14 Interlock link RC2-5119-000CN 1
15 Interlock link RC2-5118-000CN 1
17 Switch lever RC2-5124-000CN 1
18 Shaft RC2-5913-000CN 1
19 Spring, torsion RC2-5934-000CN 1
20 Cartridge lock lever RC2-5954-000CN 1
22 Spring, torsion RC2-5958-000CN 1
28 Interlock link RC2-5122-000CN 1
31 Power supply button RL1-1947-000CN 1
32 Photo interrupter, TLP1243 WG8-5696-000CN 1
36 Density detect sensor assembly RM1-4953-000CN 1
37 Lower pick up guide assembly RM1-4980-000CN 1
38 ITB kit CC468-67907 1
39 Control panel cable assembly RM1-5743-000CN 1
40 Switch cable assembly RM1-5718-000CN 1
41 Front cable assembly RM1-5723-000CN 1
42 Front lock arm assembly RM1-5532-000CN 1
43 Power supply switch assembly RM1-5697-000CN 1
44 Door switch assembly RM1-5732-000CN 1
45 Switch WC4-5171-000CN 1
46 Secondary transfer (T2) roller kit CC468-67914 1
47 Rear lock arm assembly RM1-5533-000CN 1
48 Duplex reverse guide kit CC468-67913 1
ENWW Internal components 463
