Table 8-7 Internal components (4 of 5)
Ref Description Part number Qty
1 Fusing (fixing) connecting cable assembly RM1-5714-000CN 1
2 Door stopper right link RC2-4916-000CN 1
6 Fan RK2-2416-000CN 1
11 Switch arm RC2-5943-000CN 1
16 Scanner flat cable RK2-2506-000CN 1
17 Rear cable assembly RM1-5721-000CN 1
18 Switch connecting cable assembly RM1-5719-000CN 1
19 Scanner flat cable RK2-2508-000CN 1
24 Right door rear hinge RC2-4895-000CN 1
25 MP sensor cable assembly (simplex) RM1-5750-000CN 1
27 MP sensor cable assembly (duplex) RM1-5737-000CN 1
ENWW Internal components 465
