Description Part number Table and page
Lower pick up guide assembly RM1-4980-000CN Internal components (3 of 5)
on page 463
LVPS 110V RM1-5685-000CN PCAs on page 485
LVPS 220V RM1-5686-000CN PCAs on page 485
Main drive assembly kit CC468-67918 Internal components (5 of 5)
on page 467
Motor/sensor cable assembly RM1-5752-000CN Internal components (2 of 5)
on page 461
MP sensor cable assembly (duplex) RM1-5737-000CN Internal components (4 of 5)
on page 465
MP sensor cable assembly (simplex) RM1-5750-000CN Internal components (4 of 5)
on page 465
Paper delivery assembly (duplex) RM1-4970-000CN Delivery assembly
on page 479
Paper delivery assembly (simplex) RM1-5003-000CN Delivery assembly
on page 479
Photo interrupter, TLP1243 WG8-5696-000CN Internal components (3 of 5)
on page 463
Photo interrupter, TLP1243 WG8-5696-000CN Internal components (5 of 5)
on page 467
Pick up motor cable assembly RM1-5731-000CN Internal components (5 of 5)
on page 467
Pickup roller (250 cassette) CC468-67911 Cassette paper pickup
assembly on page 471
Pickup roller (MP) CC468-67911 MP paper pickup assembly
on page 473
Plate, blanking RC2-5938-000CN External covers, panels, and
doors; on page 455
Power supply button RL1-1947-000CN Internal components (3 of 5)
on page 463
Power supply switch assembly RM1-5697-000CN Internal components (3 of 5)
on page 463
Rear cable assembly RM1-5721-000CN Internal components (4 of 5)
on page 465
Rear lock arm assembly RM1-5533-000CN Internal components (3 of 5)
on page 463
Rear Pre-exposure PCA assembly RM1-5705-000CN Internal components (5 of 5)
on page 467
Registration assembly (duplex) RM1-4969-000CN Registration assembly
on page 475
Registration assembly (simplex) RM1-5009-000CN Registration assembly
on page 475
Right door assembly (duplex) RM1-4957-000CN External covers, panels, and
doors; on page 455
Table 8-20 Alphabetical parts list (continued)
