EL-MF877-00 Page 11
Template Revision A
FIGURE 17: POWER SUPPLY 3: Screw and plastic tie locations
FIGURE 18: POWER SUPPLY 3: Screw locations
FIGURE 19: POWER SUPPLY 3: Large PCA screw locations
