NOTE: After installing the new Vacuum Fan, make sure you perform the following Service
Calibration:
●
Paper-advance calibration
Paper-advance calibration on page 127.
Vacuum Fan Cable
Removal
WARNING! Switch off the printer and remove the power cable.
1. Remove the Right Cover See Right Cover on page 216.
2. Remove the Right Connector Cover
See Right Connector Cover on page 238.
3. Disconnect the cable labelled on the Vacuum Fan PCA as “Interconnect Cable”.
