Image requirements
The image must meet the following requirements:
• .bmp file format for systems using BIOS 08
• .jpg file format for systems using BIOS 09 or BIOS 2011
• Resolution range between 424 x 320 pixels and 1024 x 768 pixels
• File size maximum of 32 kilobytes
• Maximum of 16 million colors
Command-line switches
The EREPLOGO.EXE utility accepts multiple input parameters, identified by a command line switch. It uses the following
syntax: EREPLOGO.EXE [/<Option><parameter>] as shown in Table 2.
Table 2: Command-line syntax for the EREPLOGO.EXE utility
Command
option
Valid values Description
/e None Erases current logo in Flash ROM
/fFilename ASCII Text Command to specify the .bmp or .jpg image file
used as the logo displayed during POST.
If you enter no parameters or enter invalid parameters, the utility displays a usage statement similar to the following:
HPQ EFI BIOS Logo Replace - Version 1.00
Copyright 2008 - Hewlett-Packard Corporation
Usage: EREPLOGO [/e] /fFilename
/e: Erase the current logo in the EFI BIOS
/fFilename: Bitmap or JPEG file created to be used as the logo
Command-line examples
The following examples were run on an HP Elitebook 2730p notebook with an HP logo.
Using the “/f” option to replace the existing logo
This example replaces the existing logo in the Flash ROM device with a new logo file.
C:\> EREPLOGO /fHPLOGO.JPG
HPQ EFI BIOS Logo Replace - Version 1.01
Copyright 2008 - Hewlett-Packard Corporation
Logo File Size: 21878 bytes
Flash Logo Programming Successful
Done.
Using the “/e” option to erase the logo in the Flash ROM
The following example shows how to use the erase /e option to erase an existing logo and return the display to the
default HP logo.

HP EliteBook 2170p Specifications

General

Bus type	DMI
Stepping	L1
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-3437U
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-3400 Mobile Series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	1.9 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.9 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	17 W
CPU multiplier (bus/core ratio)	19
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM77 Express
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	SD
Number of HDDs installed	1
Display surface	Matt
Display diagonal	11.6 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Intel segment tagging	Enterprise
On-board graphics card ID	0x166
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1200 MHz
Audio system	SRS Premium Sound Pro
3G standards	HSPA+
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile network generation	3G
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	-
eSATA/USB 2.0 ports quantity	0
Pointing device	Touchpad
Operating system installed	Windows 7 Professional
Form factor	Clamshell
Product type	Laptop
Product color	Stainless steel
Housing material	Metal
Country of origin	China
Processor code	SR0XE
Processor ARK ID	71259
Processor package size	31.0 x 24.0 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Battery capacity	48 Wh
Battery life (max)	8.25 h
Number of battery cells	6
AC adapter power	65 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	192 mm
Width	292 mm
Height	26.5 mm
Weight	1330 g
