HP EliteBook 2570p Specification

At A Glance
Windows 8 versions, Windows 7 versions or FreeDOS
12.5-inch diagonal LED-backlit HD display
Industrial, business rugged HP DuraCase construction features a full magnesium alloy chassis, wear-resistant HP DuraFinish,
precision aluminum-alloy hinges, and cast titanium-alloy display latches; designed to meet the military standard Mil-Std-810G
for vibration, dust, altitude, and high temperature operation*
Spill-resistant keyboard with drains
Choice of an Intel® Core™ i7, Core i5, or Core i3 standard voltage processor for maximum performance
Intel vPro technology (optional) enables you to remotely monitor, diagnose, and repair PCs over the network, even if a system's
OS is inoperable or it is powered off
Optional fixed optical drive or weight saver
Choice of 7200 rpm 2.5-inch hard drive up to 750 GB, with HP 3D DriveGuard protection; 7200 rpm Self-encrypting drive up to
500 GB, or 128/180/240GB Solid State Drive or 256 GB SED Solid State Drive
Flexible wireless connectivity options:
Integrated HP hs2350 HSPA+ Mobile Broadband Module connects to both HSPA and HSPA+ (UMTS) networks and provides
GPS functionality
Integrated HP un2430 EV-DO/HSPA Mobile Broadband Module (Gobi 3000) provides GPS functionality
Integrated Intel Centrino® 802.11 a/b/g/n 2x2, Broadcom 802.11 a/b/g/n 2x2 or Atheros b/g/n 1x1 wireless LAN module
Bluetooth® v4.0+EDR
Choice of 9-cell, 6-cell, or 3-cell battery, including HP Long Life battery, to customize weight, run-time, and battery life to your
needs
HP Power Assistant (Windows 7 only) and HP Peak Power Manager** (web download) to conserve power, increase battery run-
time, monitor power needs, and report workforce power consumption
Integrated Intel HD Graphics 4000
SRS Premium Sound PRO optimized for high fidelity audio
Security features including HP Client Security (Windows 8 only) and HP ProtectTools, with central management across HP and
non-HP client PCs
Separate launch buttons for easy access to the following features: wireless on/off, HP QuickWeb, and volume mute
DisplayPort for high resolution support
Optional HP 2570 Series Docking Station provides additional DisplayPort, eSATA port, four additional USB ports (one charging),
audio in/out ports, RJ-45, VGA, power connector, and HP Docking Station Cable Lock
Optional 720p HD Webcam
Dual pointing devices (touchpad with scroll zone and pointstick)
HP Night Light
ExpressCard/34 slot
Secure Digital slot
Low Halogen***, ENERGY STAR qualified and EPEAT Gold registered in the U.S. EPEAT status varies by country- please see
epeat.net.
* Testing was not intended to demonstrate fitness for DOD contracts requirements or for military use. Test results are not a guarantee
of future performance under these test conditions.
** HP Peak Power Manager replaces HP Power Assistant for both Win7 and Win8. HP Peak Power Manager will be available on the web
for download for existing product owners.
*** External power supplies, power cords, cables and peripherals are not Low Halogen. Service parts obtained after purchase may not
be Low Halogen.
QuickSpecs
HP EliteBook 2570p Notebook PC
Overview
DA - 14314 Worldwide — Version 12 — May 14, 2013 Page 4

HP EliteBook 2570p Specifications

General

Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
LED backlight	Yes
Display diagonal	12.5 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Bus type	DMI
Stepping	L1
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-3210M
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-3200 Mobile series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	2.5 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.1 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	25
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM77 Express
HDD speed	7200 RPM
HDD interface	SATA II
Storage media	HDD
Optical drive type	DVD Super Multi DL
Total storage capacity	500 GB
Compatible memory cards	SD
Number of HDDs installed	1
On-board graphics card ID	0x166
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Intel segment tagging	Enterprise
Audio system	SRS Pro
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	0
Keyboard layout	-
Pointing device	Touchpad
Operating system installed	Windows 8 Pro
Form factor	Clamshell
Product type	Laptop
Product color	Gray
Country of origin	China
Battery capacity	55 Wh
Battery life (max)	- h
Number of battery cells	6
AC adapter power	65 W
Sustainability certificates	ENERGY STAR
Processor code	SR0N0
Processor ARK ID	65708
Processor package size	31.0 x 24.0 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	209 mm
Width	305 mm
Height	27 mm
Weight	1630 g
