Solid-state drive
To remove the M.2 solid-state drive, use this procedure and illustration.
Table 5-4 Solid-state drive descriptions and part numbers
Description Spare part number
2 TB, PCIe, TLC L85358-002
1 TB, PCIe, TLC L85348-002
512 GB, PCIe, TLC L85360-002
512 GB, PCIe, TLC, self-encrypting drive (SED) L85368-002
512 GB, PCIe, value L85364-002
512 GB, PCIe + 32 GB Optane memory L85366-002
256 GB, PCIe, TLC L85350-002
256 GB, PCIe, TLC, self-encrypting drive (SED) M07245-002
256 GB, PCIe, value L85354-002
128 GB, PCIe, TLC M06792-002
Solid-state drive cover (included in Bracket Kit) M46057-001
Before removing the solid-state drive, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 30).
2. Remove the bottom cover (Bottom cover on page 30).
3. Disconnect the battery cable from the system board (see Battery on page 38).
Remove the solid-state drive:
▲ Use the tab (1) to lift the cover o the solid-state drive (2). The cover is held in place by clips on the
system board.
Component replacement procedures 35
