Other interfaces
IrDA
– Supported (Standard IR)
USB
– Supported via sync cable
Serial
– Supported
Sync/Data Connector
– Full RS 232 support
SD Slot
Support 4-bit SDIO and 4-bit SD/Multimedia Card type memory standard
Power Supply
Battery
Internal Rechargeable 1000 mAh Lithium-lon battery.
Estimated usage time of fully charged battery is up to 7 hours. Charging time
up to 4 hours.
Optional extended Lithium-lon batteries are available for purchase at
http://www.hp.ca/go/ipaqaccessories
or from any authorized HP reseller.
AC Power
AC Input: 100~240 Vac, 50/60 Hz, AC Input current: 0.2 Aac max
Output Voltage: 5Vdc (typical), Output Current: 2A (typical)
NOTE:
Battery run time varies based on the usage pattern of an individual user and the configuration of
the handheld. Use of backlight will significantly decrease battery run time.
AC Adapter
Dimensions
(H x W xD)
3 x 1.9 x 1.8 in (76 x 48 x 44 mm - including prongs), (may vary by model)
Cord Length
(approx.)
6 ft (1.83 m)
Power Supply Ratings
Voltage Range
100 to 240 V Switching
Input Current
0.3 Aac
Input Frequency
50 to 60 Hz
Output Voltage
5 VDC
Output Current
2 Amp
System Unit
Dimensions
(H x W x D)
4.48 x 2.75 x .53 in (114 x 70 x 13.4 mm)
Weight
4.23 oz (120 g)
Operating Temperature
32° to 104° F (0° to 40° C)
Storage Temperature
-4° to 140° F (-20° to 60° C)
Operating Humidity
90% RH
Regulatory Marks
Electrical
FCC Class B, Canadian ICES-003 Class B, CE
Safety
UL or CSA, NRTL C-UL, NOM
Design Features
4 programmable application launch buttons – defaults Calendar, Contacts, Messaging and Today buttons.
Push and hold application buttons to launch additional programs: Windows Media Player, HP Image Zone,
Record; Landscape/Portrait toggle
QuickSpecs
HP iPAQ rz1700 series Pocket PC
Standard Features
DA - 11969 Canada — Version 6 — August 23, 2005
Page 4
