3 Interface Boards and Mass-Storage Drives
Connectors and Sockets
Internal Audio
Connectors
External Audio
Connectors
On the PC Workstation there is a Headphone Out jack and Microphone In jack
on the Audio Front Panel. A Line In jack, Line Out jack and Mic In jack
connector are located on the rear panel. These external jacks are standard
connectors.
CD AUDIO Connector AUX Connector
Pin Signal I/O Pin Signal I/O
1 Analog Ground - 1 Analog Ground -
2 CD Right Channel IN 2 AUX Right Channel IN
3 Analog Ground - 3 Analog Ground -
4 CD Left Channel IN 4 AUX Left Channel IN
Audio Front Panel Connector Front Panel Microphone Connector
Pin Signal I/O Pin Signal I/O
1 Analog Ground - 1 MIC Signal + Power (tip) IN
2 Key Way - 2 Analog Ground -
3 Front Panel input Left IN 3 MIC Signal + Power (ring) -
4 Front Panel Return Left OUT
5 Front panel Input Right IN
6 Front Panel Return Right OUT
7 Volume Low Limit -
8 Volume High Limit -
9 Volume Adjust Left -
10 Volume Adjust Right -
