HP L1702 User Manual

HP L1702
25
R406
27K 1/16W
D402
SMD IN4148
R408
360K 1/16W
C406
332/NPO
-
+
IC401B
LM393
5
6
7
84
R409
100K 1/16W
R401
1K 1/10W
R418
10K 1/16W
R411
150K 0805
Q402
RK7002
C401
1uF
BU_R
A
11Friday, September 23, 2005
Title
Size Document Number Rev
Date: Sheet
of
+12V
C405
102/NPO
BU_L
R405
27K 1/16W
R415
33K 1/16W
D401
SMD IN4148
R417
10K 1/16W
R416
33K 1/16W
R407
300K 1/16W
Q401
PMBS3904
32
1
R402
470 1/8W
DIM
C404
104
ZD401
RLZ5.6B
R404
56K 1/16W
-
+
IC401A
LM393
3
2
1
84
R410
130K
C403
682
R414
22K 1/16W
PWPC715L1236-A
