17" LCD Color Monitor HP L1710
24
DGND 1,2,3
+
C402
100uF16V
CN401
CONN
1
2
3
4
5
6
7
8
9
Volume#
R401
10K 1/16W
VCC3.3
Mut e 2
Volume# 2
Q403
2N3904S-RTK/PS
BKLT-VBRI
R404 4K7 1/16W
*12/28 change to LDO due to
internal ripple too big
C410
0.1uF/16V
CMVCC
C_PANEL_INDEX
VCC3.3
BKLT-EN
C411
0.1uF/16V
-1-3
HP L1750/L1950 A
55Thursday , July 19, 2007
715G2559-1-3
备注
05 Power
G2559-1-3-X-2-070719
OEM MOD EL Size
Rev
Date
Sheet
of
TPV MODEL
PCB NAME
备注
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
线路图编号
R405
10K 1/16W
MVCC
BKLT-VBRI
C406
NC
+
C407
100uF16V
VCC3.3
VCC1.8
FB402 NC
U701 AP1117E33LA
1
23
VSS
VOUTVIN
Mut e
C409
0.1uF/16V
CMVCC
adj_BACKLIGHT 2
CMVCC
on_BACKLIGHT 2
C405
0.1uF/16V
MVC C
R406 1K 1/16W
CMVCC
PANEL_ID#
U702
AP1117E18LA
3 2
1
VI VO
GND
R402 3.3 OHM 2W
+
C408
100uF16V
R403
10K 1/16W
BKLT-EN
VCC3.3 C401
0.1uF/16V

HP L1710 Specifications

General

3D	No
HD type	-
Panel type	TFT
Pixel pitch	0.264 x 0.264 mm
Display surface	Matt
Display diagonal	17 \
Display resolution	1280 x 1024 pixels
Display technology	LCD
Vertical scan range	50 - 77 Hz
Horizontal scan range	24 - 83 kHz
Contrast ratio (typical)	800:1
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1280 x 1024 (SXGA)
UNSPSC-code	43211902
On/off switch	Yes
Power requirements	100 - 240 VAC, 50 - 60 Hz
Display viewable area (HxV)	432 mm
HDMI ports quantity	0
Certification	ISO 13406-2 pixel defect guidelines, MPR-II, CISPR, VCCI, CSA(Canada), ACA (Australia), TUV and GS Mark (German ergonomic), BSMI (Taiwan), CCC (China), MIC (South Korea), NOM (Mexico), Eastern European approvals, CE Marking, FCC approval, TCO '03 (emissions, ergonomics, environment), Microsoft Windows certified (Microsoft Windows 2000, Microsoft Windows XP, and Windows Vista), UL listed, GOST (Russia), SASO (Saudi Arabia), Restrictions of Hazardous Substances (RoHS) Directive, 2002/95/EC, Waste Electrical and Electronic Equipment (WEEE) Directive, 2002/96/EC
Product color	Silver
Country of origin	China
Market positioning	Business
Tilt angle range	-5 - 25 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	2 W
Power consumption (typical)	30 W
Operating temperature (T-T)	5 - 35 °C
Non-operating relative humidity (non-condensing)	5 - 90 %
Package weight	6100 g
Sustainability certificates	ENERGY STAR
Cables included	AC, VGA

Weight and Dimensions

Depth (with stand)	192 mm
Width (with stand)	377 mm
Height (with stand)	386 mm
Weight (with stand)	4700 g
Depth (without stand)	57 mm
Height (without stand)	316 mm
Weight (without stand)	3920 g
