Page #72 background image
17" LCD Color Monitor HP L1710
72
H40G 581690 3E LABEL
H41G160669024B L1*10/L1908* APD(459446-374)
PWPC741CH1H POWER BOARD
E08907 S89G179T30NE05 LVDS ASSY
Diversity of T77CMSDDHNHPN1E Compared with T77GMSDKHNHPNNE
Location Part No. Description
041G780069089A warranty card(390490-AA1)
041G780069090A WARRANTY(C8942-90052)
E08901 089G414A19N IS POWER CORD
E750 750GLC170A7P22Z0HP CPT CLAA170EA07P 8J4 WJ CPT
A15G0250 2104C MAIN FRAME 17"
CBPC7CMSHPH1 CONVERSION BOARD
H70G1606690 9C L1*10/L1908* CD(459540-B24)
PWPC741CH1H POWER BOARD
E08907 S89G179T30NE05 LVDS ASSY
Diversity of T77CMSDKHNHPN1E Compared with T77GMSDKHNHPNNE
Location Part No. Description
E750 750GLC170A7P22Z0HP CPT CLAA170EA07P 8J4 WJ CPT
A15G0250 2104C MAIN FRAME 17"
CBPC7CMSHPH1 CONVERSION BOARD
PWPC741CH1H POWER BOARD
E08907 S89G179T30NE05 LVDS ASSY
Diversity of T77CMSDDHNHAN1E Compared with T77GMSDKHNHPNNE
Location Part No. Description
E750 750GLC170A7P22Z0HP CPT CLAA170EA07P 8J4 WJ CPT
A15G0250 2104C MAIN FRAME 17"
CBPC7CMSHPH1 CONVERSION BOARD
H41G160669024B L1*10/L1908* APD(459446-374)
PWPC741CH1H POWER BOARD
E08907 S89G179T30NE05 LVDS ASSY
Diversity of T77CMSDLHNHPN1E Compared with T77GMSDKHNHPNNE
Location Part No. Description
E08901 089G412A19NIS3 POWER CORD
E750 750GLC170A7P22Z0HP CPT CLAA170EA07P 8J4 WJ CPT
A15G0250 2104C MAIN FRAME 17"
CBPC7CMSHPH1 CONVERSION BOARD

Other manuals for HP L1710

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP L1710 and is the answer not in the manual?

HP L1710 Specifications

General IconGeneral
3DNo
HD type-
Panel typeTFT
Pixel pitch0.264 x 0.264 mm
Display surfaceMatt
Display diagonal17 \
Display resolution1280 x 1024 pixels
Display technologyLCD
Vertical scan range50 - 77 Hz
Horizontal scan range24 - 83 kHz
Contrast ratio (typical)800:1
Viewing angle, horizontal160 °
Display brightness (typical)300 cd/m²
Supported graphics resolutions1280 x 1024 (SXGA)
UNSPSC-code43211902
On/off switchYes
Power requirements100 - 240 VAC, 50 - 60 Hz
Display viewable area (HxV)432 mm
HDMI ports quantity0
CertificationISO 13406-2 pixel defect guidelines, MPR-II, CISPR, VCCI, CSA(Canada), ACA (Australia), TUV and GS Mark (German ergonomic), BSMI (Taiwan), CCC (China), MIC (South Korea), NOM (Mexico), Eastern European approvals, CE Marking, FCC approval, TCO '03 (emissions, ergonomics, environment), Microsoft Windows certified (Microsoft Windows 2000, Microsoft Windows XP, and Windows Vista), UL listed, GOST (Russia), SASO (Saudi Arabia), Restrictions of Hazardous Substances (RoHS) Directive, 2002/95/EC, Waste Electrical and Electronic Equipment (WEEE) Directive, 2002/96/EC
Product colorSilver
Country of originChina
Market positioningBusiness
Tilt angle range-5 - 25 °
Cable lock slot typeKensington
Panel mounting interface100 x 100 mm
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)2 W
Power consumption (typical)30 W
Operating temperature (T-T)5 - 35 °C
Non-operating relative humidity (non-condensing)5 - 90 %
Package weight6100 g
Sustainability certificatesENERGY STAR
Cables includedAC, VGA
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)192 mm
Width (with stand)377 mm
Height (with stand)386 mm
Weight (with stand)4700 g
Depth (without stand)57 mm
Height (without stand)316 mm
Weight (without stand)3920 g
