HP L1908w Specification

Sleep 6.82 BTU/hr 6.82 BTU/hr 6.82 BTU/hr
Off 3.41 BTU/hr 3.41 BTU/hr 3.41 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming the service level is
attained for one hour.
Longevity and
Upgrading
Upgradeability features contained in the product include:
One upstream and two downstream USB ports
Ergonomics The monitor meets the ergonomic requirement of EN-ISO 13406-2 for
flat panel displays.
Additional Information This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive, 2002/96/EC.
Plastics parts weighing over 25 grams used in the product are marked
per ISO 11469 and ISO1043.
Display meets the requirement for low frequency electromagnetic fields
per MPR-II, TCO, and prEN50279 A/B/C.
This product contains 0% recycled materials (by wt.)
This product is 95% recyclable when properly disposed of at end of life.
Packaging Materials
Corrugated Carton – 0.96 kg
HDPE Bag – 0.09 kg
Polystyrene – 0.55 kg
Material Usage This product does not contain any of the following substances in excess
of regulatory limits (refer to the HP General Specification for the
Environment at: www.hp.com/hpinfo/globalcitizenship/environment/
supplychain/gen_specifications.html )
Asbestos
Certain Azo Colorants
Certain Brominated Flame Retardants – may not be used as
flame retardants in plastics
Cadmium
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Halogenated Diphenyl Methanes
Lead carbonates and sulfates
Lead and Lead compounds
Mercuric Oxide Batteries
Nickel – finishes must not be used on the external surface
designed to be frequently handled or carried by the user.
Ozone Depleting Substances
Polybrominated Biphenyls (PBBs)
Polybrominated Biphenyl Ethers (PBBEs)
Polybrominated Biphenyl Oxides (PBBOs)
Polychlorinated Biphenyl (PCB)
Polychlorinated Terphenyls (PCT)
Polyvinyl Chloride (PVC) – except for wires and cables, and
certain retail packaging has been voluntarily removed from most
applications.
Radioactive Substances
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Packaging HP follows these guidelines to decrease the environmental impact of
QuickSpecs
HP L1908w 19-inch Widescreen LCD Monitor
Technical Specifications
DA - 12826 Worldwide QuickSpecs — Version 3 — 12/17/2007 Page 4

HP L1908w Specifications

General

3D	No
Panel type	TFT
Pixel pitch	0.285 x 0.285 mm
Display surface	Matt
Display diagonal	19 \
Separate H/V sync	Yes
Display resolution	1440 x 900 pixels
Display technology	LCD
Native aspect ratio	16:10
Vertical scan range	50 - 76 Hz
Maximum refresh rate	75 Hz
Horizontal scan range	24 - 83 kHz
Viewable size diagonal	482.5 mm
Viewable size, vertical	256.7 mm
Contrast ratio (typical)	1000:1
Display number of colors	-
Viewable size, horizontal	409.8 mm
Viewing angle, horizontal	160 °
Display scanning frequency	Horizontal frequency: 24-83 kHz, Vertical frequency: 50-76 Hz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1440 x 900 (WXGA+)
I/O ports	VGA
HDMI ports quantity	0
Certification	TCO 03, Taiwan Green Mark, CECP
Product color	Black
Country of origin	China
Tilt angle range	-5 - 30 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	DEU, DUT, ENG, ESP, FRE, ITA, JPN
UNSPSC-code	43211902
Audio included	No audio included at platform level
Security features	Kensington Lock-ready
Power requirements	100 - 240 VAC, 50 - 60 Hz
Multimedia connections	Optional HP Flat Panel Speaker Bar: powered directly by the monitor or PC, the Speaker Bar attaches to the monitor's lower bezel to bring full audio support to select HP Flat Panel Monitors. Features include dual speakers with full sound range and external jack for headphones, part number EE418AA. For more information, refer to the product's Quick Specs. Optional HP Flat Panel Monitor Quick Release: an easy-to-use, VESA-compliant, flat panel monitor mounting solution that allows you to quickly and securely attach a flat panel monitor to a variety of stands, brackets, arms or wall mounts, part number EM870AA. For more information, refer to the product's Quick Specs.
Recommended resolution	Preset VESA Graphic Modes (non-interlaced): 1280 x 1024 @ 60 and 75 Hz, 1024 x 768 @ 60 and 75 Hz, 1152 x 870 @ 75 Hz (Mac), 1152 x 900 @ 66 Hz (Sun), 832 x 624 @ 75 Hz (Mac), 800 x 600 @ 60 and 75 Hz, 720 x 400 @ 70 Hz, 640 x 480 @ 60 and 75 Hz
Active display area (W x H)	409.8 x 256.7 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	50 W
Power consumption (off)	1 W
Power consumption (standby)	2 W
Power consumption (typical)	37 W
Operating altitude	0 - 3658 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-34 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Non-operating relative humidity (non-condensing)	5 - 90 %
Package depth	174 mm
Package width	536 mm
Package height	423 mm
Package weight	6450 g
Sustainability certificates	EPEAT Silver, ENERGY STAR
Cables included	AC, VGA
Power cable length	1.9 m

Weight and Dimensions

Depth (with stand)	187 mm
Width (with stand)	446 mm
Height (with stand)	370 mm
Weight (with stand)	5100 g
Depth (without stand)	59 mm
Height (without stand)	301 mm
Weight (without stand)	4200 g
