QuickSpecs
HP L1908wm 19-inch Widescreen LCD Monitor
Technical Specifications
Worldwide — Version 1 — September 25, 2007 Page 2
Response Time (typical)*
≤5 ms (on/off)
Pixel Pitch .285 mm
Backlight Lamp Life
(to half brightness)
50 K hours
*All performance specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary either higher or lower.
Buttons or Switches Auto adjust/OSD down, OSD UP, OSD menu select, power
Languages English, Brazilian Portuguese, French, German, Spanish, Italian, Dutch, and
Japanese, S. Chinese
On Screen Display
(OSD) Controls
User Controls Brightness, contrast, positioning, color temperature (6500k, 9300k,
custom), individual color control, serial number, display, clock, clock phase,
monitor management, factory reset, zoom, volume control
Horizontal Frequency 24 to 83 kHz
Vertical Frequency 50 to 76 Hz
Native Resolution 1440 x 900 @ 60 Hz
1280 x 1024 @ 60 Hz and 75 Hz
1024 x 768 @ 60 Hz and 75 Hz
800 x 600 @ 60 Hz and 75 Hz
Preset VESA Graphic Modes
(non-interlaced)
640 x 480 @ 60 Hz and 75 Hz
Text Mode 720 x 400 @ 70 Hz
Mac Mode 1152 x 870 @ 75 Hz and 832 x 624 @ 75 Hz
Sun Mode 1152 x 900 @ 66 Hz
Maximum Pixel Clock Speed 140 MHz (analog input)
User Programmable Modes Yes, 10
Anti-Glare Yes
Anti-Static Yes
Signal Interface/
Performance
Default Color Temperature 6500 K
Plug and Play Yes
Self Powered USB 2.0 Hub No
Input Signal DVI-D connector (DVI cable not included), 15-pin D-sub (analog VGA), VGA
cable included
Input Impedance 75 ohms ± 10%
Sync Input TTL separate synch or Composite Sync
VGA Cable 15 pin D-sub VGA
Video/Other Inputs
VGA Cable Length 5.9 ft (1.8 m)
Speakers Integrated rear firing
Output power 2 watt per channel
Controls Volume, OSD selectable
Audio
Audio cable Included, length: 5.9 ft (1.8 m)
Input Power Auto-Sensing, 100 to 240 VAC, 50 +/-3 Hz to 60 +/-3 Hz) Power
Frequency 45 to 63 Hz
