Technical Specifications
L1740 Flat Panel Monitor (Continued)
Maximum Graphics Resolution 1280 x 1024 (75 Hz) analog and digital modes
Text Mode 720 x 400
Dot Pitch 0.264 x 0.264 mm
Horizontal Frequency 30 to 83 kHz
(analog mode)
Vertical Refresh Rate 56 to 76 Hz
(analog mode)
Environmental Requirements
Temperature:
Operating Temperature
41 to 95° F 5 to 35° C
Non-operating Temperature
-4 to 140° F -20 to 60° C
Relative Humidity 20 to 80%
Power Source 100 - 240 VAC, 60-50 Hz
Power Consumption <70 watts typical
Input Terminals 15-pin D-type connector with cable included
DVI-D connector with DVI-D cable not included
(available on select models)
B–2 User Guide
