6.
Lift the rear of the printer slightly. Grasp the lower right back
corner. With your thumbs, flex the plastic toward you, up, and
out. Figure 19 shows this process for the rear right corner.
Repeat the process for the left rear corner.
Note
Note the position of the tabs and the catches
carefully. This step may require considerable
twisting and flexing of the plastic in order to free
the release tabs.
7.
Lift the printer cover straight up.
Figure 19 Releasing the Back Corner of the Top Cover
HP LaserJet 5P/5MP, 6P/6MP Printer Service Supplement
Removal and Replacement
47
