REF PART NO. QTY DESCRIPTION
1 RG5-1709-000CN 1 Top Door Assembly
2 RG5-1699-000CN 1 Power Connector Cover Assy
3 RB1-5931-000CN 1 Cover, Main
4 RB1-5935-000CN 1 Button, Lock
5 RS5-2228-000CN 1 Spring, Compression
6 RB1-5936-000CN 1 Guide, Lock Button
7 RG5-1697-000CN 1 Paper Feed Tray Assembly
8 RB1-5939-000CN 1 Arm, Tray 1 Sensor
9 C3150-00004
C3155-00001
1 Nameplate (HP LaserJet 5P)
Nameplate (HP LaserJet 5MP)
10 RS5-2418-000CN 1 Spring, Torsion
11 RB1-5937-000CN 1 Stopper, Hinge, Right
12 RB1-5938-000CN 1 Stopper, Hinge, Left
13 RS5-2419-000CN 1 Spring, Torsion
14 RF5-0593-000CN 1 Brush, Mirror
15 RB1-5934-000CN 1 Cover, Interface Connector
16 RG5-1710-000CN 1 Side Cover Assembly
17 RB1-5927-000CN 1 Bushing
18 RB1-5924-000CN 1 Tray, Sub-assy, Face-Up
19 RG5-1707-000CN 1 Face-Up Tray Assembly
Table 12.
Covers and Doors
HP LaserJet 5P Printer Service Supplement
Parts and Diagrams
71
