7. Clear the jam by carefully pulling the paper straight out.
8. Push the fuser straight into the product until it snaps into place.
9. Insert the right-hand side of fuser-entrance guide into the product, carefully flex the left-hand side of
the guide, and then push it back into the product until the pins on the guide snap into the holes on
the product chassis.
1
2
292 Chapter 13 Solve problems ENWW
