HP LV1911 User Manual

Altitude – Non-operating 0 to 12,192 m (0 to 40,000 ft)
White LED Backlights Yes
CCFL Panel No
Arsenic-Free Display
Glass
Yes
Low Halogen2 No
Mercury-Free Display
Backlighting
Yes
Environmental Data Eco-Label Certifications
& declarations
This product has received or is in the process of being certified to the following
approvals and may be labeled with one or more of these marks:
IT ECO declaration
Energy Consumption 115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
Normal Operation 14.75 W 14.72 W 14.75 W
Sleep 0.20 W 0.23 W 0.23 W
Off 0.14 W 0.16 W 0.17 W
Heat Dissipation * 115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
Normal Operation 50 BTU/hr 50 BTU/hr 50 BTU/hr
Sleep 0.6 BTU/hr 0.7 BTU/hr 0.7 BTU/hr
Off 0.4 BTU/hr 0.5 BTU/hr 0.5 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming the
service level is attained for one hour.
Additional Information This product is in compliance with the Restrictions of Hazardous Substances
(RoHS) directive - 2002/95/EC.
This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive - 2002/96/EC.
This product is in compliance with California Proposition 65 (State of
California; Safe Drinking Water and Toxic Enforcement Act of 1986).
Plastics parts weighing over 25 grams used in the product are marked per
ISO 11469 and ISO1043.
This product contains 34% post-consumer recycled plastic (by wt.)
This product is 96.7% recycle-able when properly disposed of at end of life.
Packaging Materials External: PAPER/Cardboard & misc 1130 g
Internal: PLASTIC/Polyethylene low
density
12 g
RoHS Compliance Hewlett-Packard is committed to compliance with all applicable environmental
laws and regulations, including the European Union Restriction of Hazardous
Substances (RoHS) Directive. HP's goal is to exceed compliance obligations by
meeting the requirements of the RoHS Directive on a worldwide basis. By July 1,
2006, RoHS substances will be virtually eliminated (virtually = to levels below
legal limits) for all HP electronic products subject to the RoHS Directive, except
where it is widely recognized that there is no technically feasible alternative (as
indicated by an exemption under the EU RoHS Directive).
Material Usage This product does not contain any of the following substances in excess of
QuickSpecs
HP LV1911 18.5-inch LED Backlit LCD Monitor
Technical Specifications
DA - 14245 North America — Version 6 — April 18, 2013 Page 4

HP LV1911 Specifications

General

3D	No
Aspect ratio	16:9
Display diagonal	18.5 \
Display resolution	1366 x 768 pixels
Supported video modes	720p
Viewing angle, vertical	50 °
Contrast ratio (dynamic)	3000000:1
Contrast ratio (typical)	600:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	90 °
Display brightness (typical)	200 cd/m²
Supported graphics resolutions	1366 x 768
On/off switch	Yes
Ethernet LAN (RJ-45) ports	0
HDCP	-
Certification	EPEAT Silver
Product color	Black
Country of origin	China
LED indicators	Power
Tilt angle range	-5 - 19 °
Panel mounting interface	- mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	19 W
Power consumption (standby)	0.5 W
Power consumption (typical)	17 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	170.2 mm
Height (with stand)	339.5 mm
Depth (without stand)	47.5 mm
Width (without stand)	446.1 mm
Height (without stand)	281.5 mm
Weight (without stand)	2700 g
