* Configurations of the HP Mini 5102 that are ENERGY STAR qualified are identified as HP Mini 5102
ENERGY STAR on HP websites and on
www.energystar.gov
.
** EPEAT registration varies by country. See
www.epeat.net
for registration status by country.
EPEAT status listed above applies to U.S.
HP 40W AC Adapter
Dimensions
3.66 x 1.57 x 1.14 in (9.3 x 4.0 x 2.9 cm)
Weight
0.35 lb (160 g)
Input
100 to 240 VAC
Input Efficiency
83% min at 115 VAC
Input frequency range
47 to 63 Hz
Input AC current
1.1 A at 90 VAC, 0.55 A at 180 VAC
Output
Output power
40W
DC output
19.5V
Hold-up time
5 msec at 115 VAC input
Output current limit
<5.0A, Over voltage protection- 29V max
automatic shutdown
Connector
2 pin/grounded, mates with interchangeable cords
Environmental Design
Operating temperature
32° to 104° F (0° to 40° C)
Non-operating (storage)
temperature
-4° to 149° F (-20° to 65° C)
Altitude
0 to 10,000 ft (0 to 3,048 m)
Humidity
20% to 80%
Storage Humidity
10% to 90%
EMI and Safety
Certifications
CE Mark - full compliance with LVD and EMC directives; Worldwide safety
standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals -
C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B,
CCC, NOM-1 NYCE; MTBF - over 200,000 hours at 25°C ambient condition.
NOTE:
Unless otherwise noted, temperature limits listed in the following component specifications relate to the internal temperatures
of these components and not to the environment in which the PC is operating.
QuickSpecs
HP Mini 5102
Technical Specifications
DA - 13514 Canada — Version 18 — October 8, 2010
Page 12
