HP OMEN 17 Product End-Of-Life Disassembly Instructions

EL-MF877-00 Page 2
Template Revision C
Last revalidation date 09-May-2018
HPI instructions for this template are available at EL-MF877-01
Item Description Notes
Quantity of
items
included in
product
greater than 2.5 cm in diameter or height
External electrical cables and cords
DC Cable for External Power Supply
2
Gas Discharge Lamps
Plastics containing Brominated Flame Retardants
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
Components and waste containing asbestos
Components, parts and materials containing
refractory ceramic fibers
Components, parts and materials containing
radioactive substances
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components and
materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment
including the required steps to remove the external enclosure:
1. Remove lower
2. Remove battery
3. Remove HDD
4. Remove bracket and DC-in cable
5. Remove thermal module
6. Remove IO/B
7. Remove wlan card, SSD bracket, SSD module
8. Remove MB
9. Remove Power/B, Sensor/B
10. Remove speaker, TP button
11. Remove hinge up
12. Remove Bezel
13. Remove hinge
14. Remove Panel
15. Remove Panel bracket
16. Remove antenna cable, camera module

HP OMEN 17 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black, Carbon, Red
Country of origin	China
Market positioning	Gaming
Internal memory	8 GB
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	16 GB
Memory layout (slots x size)	2 x 4 GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	1000 GB
Compatible memory cards	SD
Number of HDDs installed	1
Display surface	Matt
Display diagonal	17.3 \
Native aspect ratio	16:9
On-board graphics card ID	0x191B
Discrete graphics card model	NVIDIA® GeForce® GTX 960M
On-board graphics card model	Intel® HD Graphics 530
Discrete graphics card memory	2 GB
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.7 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	950 MHz
Speakers manufacturer	Bang & Olufsen
Number of built-in speakers	2
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	0
Sustainability certificates	EPEAT Silver, ENERGY STAR
Cable lock slot type	Kensington
Password protection type	Power on
AC adapter power	120 W
Battery capacity	62 Wh
Number of battery cells	6
Keyboard layout	QWERTY
Pointing device	Touchpad
Bus type	DMI3
Stepping	R0
Tjunction	100 °C
Processor cache	6 MB
Processor cores	4
Processor model	i5-6300HQ
System bus rate	8 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel® Core™ i5-6300 Mobile Series
Processor socket	BGA 1440
Processor codename	Skylake
Processor frequency	2.3 GHz
Processor cache type	Smart Cache
Configurable TDP-down	35 W
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	45 W
Maximum number of PCI Express lanes	16
Processor code	SR2FP
Processor ARK ID	88959
Processor package size	42 x 28 mm
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Intel Secure Key Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00

Weight and Dimensions

Depth	279 mm
Width	416 mm
Height	29.9 mm
Weight	2750 g
