EL-MF877-00 Page 2
Template Revision A
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Size (if
applicable)
Description #1 SCREW DRIVER(PHILLIPS HEAD)
Description #2 SCREW DRIVER(PHILLIPS HEAD)
Description #3 SCREW DRIVER(PHILLIPS HEAD)
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. Remove Stand Base From Display Head
2. Remove Rear Cover From Display Head
3. Remove Bracket Assy From Display Head
4. Remove Mid cover From Display Head
5. Remove Front Cover From Display Head
6. Disassemble Front Cover
7. Disassemble Bracket ASSY
8. Disassemble Stand ASSY
9. Disassemble Panel ASSY
10.
11.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).
