HP Pavilion 32 User Manual

EL-MF877-00 Page 2
Template Revision C
Last revalidation date 09-May-2018
HPI instructions for this template are available at EL-MF877-01
Item Description Notes
Quantity
of items
included
in
product
Gas Discharge Lamps
0
Plastics containing Brominated Flame Retardants
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)
0
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and
toner
Include the cartridges, print heads, tubes, vent chambers,
and service stations.
0
Components and waste containing asbestos 0
Components, parts and materials containing
refractory ceramic fibers
0
Components, parts and materials containing
radioactive substances
0
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components and
materials requiring selective treatment can be removed.
Tool Description Tool Size (if
applicable)
Screw driver of "+" type
H
exagonal nut screw driver for DVI and D
-
SUB connector
Scraper
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment
including the required steps to remove the external enclosure:
1. Remove the base assy through pushing the key on rear cover
2. Remove the rear cover and bezel through remove screws on bottom side.
3. Remove the hinge
4. Remove the tapes and the pins
5. Remove the screws to remove next to connector side
6. Remove the pin and white tapes and then remove mainframe to get panel
7. Remove the screws and pins to take out main board and side USB board
8. Remove the pins from main board and USB board to get clear EE board and main frame
9. Remove key board and LED board mount on rear cover to get clear rear cover

HP Pavilion 32 Specifications

General

3D	No
Panel type	WVA
Pixel pitch	0.276 x 0.276 mm
Screen shape	Flat
Display diagonal	32 \
Display technology	LCD
Native aspect ratio	16:9
Viewable size, vertical	398.52 mm
Contrast ratio (typical)	3000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	708.48 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	-
HDCP	Yes
VGA (D-Sub) ports quantity	0
Tilt angle range	-5 - 21 °
AC input voltage	90 - 265 V
AC input frequency	45/63 Hz
Power consumption (max)	72 W
Power consumption (off)	0.35 W
Annual energy consumption	60 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	54 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 70 %
Product color	Black
Country of origin	China

Weight and Dimensions

Depth (with stand)	178.9 mm
Width (with stand)	739.9 mm
Height (with stand)	522.3 mm
Weight (with stand)	9800 g
Depth (without stand)	53.2 mm
Height (without stand)	433.4 mm
Weight (without stand)	8200 g
