Start Here
Your PC may look different from
the ones shown here. Component,
connector location, type, and
number vary by model.
A — CD storage (select models)
B — CD-ROM or CD-RW drive
C — DVD-ROM or DVD+RW/+R drive
D — Diskette (floppy) drive
E — On button/indicator
F — Hard disk activity indicator
G — Door opened to show connectors
H — FireWire
®
K — USB 2.0 (two shown)
A
C
D
E
B
PC Front
F
G
K
H
