Item Component Spare part
number
For use with all computer models:
Atheros WB225 1x1 802.11b/g/n BT Combo 655795-001
Broadcom BCM94313HMGBLP1 802.11b/g/n 1x1 Combo HMC 657325-001
For use only with computer models equipped with an AMD processor:
Broadcom 4313 802.11b/g/n 1×1 WiFi and 2070 Bluetooth 2.1+EDR Combo adapter
(BT3.0+HS ready)
600370-001
For use only with computer models equipped with an Intel processor:
802.11 b/g/n 1×2 Intel Centrino Wireless-N 1030 + Bluetooth combo 631956-001
Broadcom 802.11 2×2 b/g/n wireless LAN + Bluetooth (BT 4.0 + HS support) combo 636672-001
(15) Hard drive (does not include the hard drive bracket, connector cable, isolators, or screws. These components
are included in the Hard Drive Hardware Kit, spare part number 664913-001):
640-GB, 5400-rpm, SATA, 7.0-mm 603785-001
500-GB, 7200-rpm, SATA, 7.0-mm 634925-001
320-GB, 7200-rpm, SATA, 7.0-mm 634862-002 and
641672-001
160-GB solid-state drive 659933-001
128-GB solid-state drive 675097-001
For use only with computer models equipped with an AMD processor and with WWAN
capability:
640-GB, 5400-rpm, SATA, 7.0-mm 669300-001
500-GB, 5400-rpm, SATA, 7.0-mm 669299-001
Hard Drive Hardware Kit (not illustrated, includes the hard drive bracket, connector cable,
isolators, and screws)
NOTE: See
Mass storage devices on page 27 for more Hard Drive Hardware
Kit information.
664913-001
(16) Service door (includes two rubber feet and shielding):
In charcoal finish 659503-001
In ash black finish 659504-001
In ruby red finish 677714-001
In ruby red finish 678158-001
For use with Alexandre Herchcovitch Special Edition computer models 683098-001
(17) Rubber Kit (includes two rear corner covers and four rubber feet) 664996-001
(18) Battery:
6-cell, 55-Whr, 2.55-Ah Li-ion battery 646757-001
3-cell, 28-Whr, 2.55-Ah Li-ion battery 646755-001
24 Chapter 3 Illustrated parts catalog
