Illustrated parts catalog
Maintenance and Service Guide 3–5
Intel Celeron processors (1-MB L2 cache, 667-MHz FSB)
■ 900 2.20-GHz processor 534419-001
■ 585 2.16-GHz processor 519898-001
■ T1700 1.83-GHz processor 534084-001
■ T1600 1.66-GHz processor 532324-001
(13) Power connector cable 533465-001
(14) USB board (does not include USB board cable) 531866-001
USB board cable (included in “Cable Kit” on page 13)
(15) Base enclosure (with card reader, includes rubber feet) 531205-001
Rubber Kit (not illustrated, includes 6 rubber feet) 531213-001
(16) Battery, 6-cell, 2.20-Ah, 47-Wh 531775-001
(17) Bluetooth® module (does not include Bluetooth cable) 483113-001
Bluetooth cable (not illustrated) (included in “Cable Kit” on page 13)
(18) Hard drive (includes hard drive bracket and connector)
500-GB, 5400-rpm 517848-001
320-GB, 5400-rpm 517847-001
250-GB, 5400-rpm 517846-001
160-GB, 5400-rpm 517845-001
Hard Drive Hardware Kit (not illustrated, includes connector, bracket, and screws) 531204-001
(19) RTC battery 449729-001
(20) Memory modules
PC2-6400, 800-MHz, DDR2
2-GB 517844-001
1-GB 517843-001
(21) Wireless (WLAN) module
Atheros AR9280 802.11 a/g/n WLAN module:
■ For use in Canada, the Cayman Islands, Guam, Puerto Rico, the U.S. Virgin Islands, and
the United States
482260-001
(Continued)
Item Description Spare Part Number
