122 Getting Started (features vary by model)
2-slot memory card reader (select models only)
A Activity light
F Upper slot
G Lower slot
Card Insert the media
2-slot reader
location
Secure Digital (SD)
Memory Card
Facing up
(gold connector fingers down)
F (upper)
MultiMediaCard (MMC) Facing up
(gold connector fingers down)
F (upper)
Memory Stick (MS)
Memory Card
Facing up
(gold connector fingers down)
F (upper)
Memory Stick (MS-Pro)
Memory Card
Facing up
(gold connector fingers down)
F (upper)
SmartMedia (SM)
Memory Card
Facing down
(gold connector fingers up)
F (upper)
xD media Facing up
(gold connector fingers down)
F (upper)
IBM Microdrive disk drive Receptacle edge (holes) G (lower)
CompactFlash Type I media Receptacle edge (holes) G (lower)
CompactFlash Type II media Receptacle edge (holes) G (lower)
NOTE: Do not use SM and xD media in the memory card reader at the same time. Only
the first one that is inserted is recognized by the memory card reader.
