hp pavilion f1503/f1703 LCD Monitor
Adjusting the Monitor Settings
27 English
Setting menus
The menus on the OSD Main Menu in the On Screen Display screen
offer different setting options, shown in the following table:
Icon Setting menu Setting description
Brightness/
Contrast
Adjusts the brightness or the difference
between the light and dark area.
Image Control Adjusts the:
• Horizontal position of the screen image.
• Vertical position of the screen image.
• Frequency of the pixel clock to minimize
vertical bar.
• Phase value to minimize horizontal jitters.
Advanced Displays a sub-menu with two options:
• Color: Adjusts the color tint of white, and
the red, green, and blue (RGB) mix for
colors.
• OSD (On Screen Display) settings: Adjusts
the position, timeout, and notification
features of the On Screen Display
window.
Auto
Configuration
Adjusts the main settings and produces a
stable, centered image.
Factory settings Resets the display to original factory settings
for color, brightness, phase, and clock.
Language Shows the language of the OSD window.
Information Shows the current resolution and refresh rate;
shows the serial number of the display; shows
the power-on hours, and the backlight hours.
Exit Closes the OSD window.
