HP Pavilion f1503 - f1703 Monitor Specifications

hp pavilion f1503/f1703 LCD Monitor
Technical Specifications for the f1703 Monitor
45 English
Technical Specifications for the f1703 Monitor
f1703 17-inch monitor
Liquid Crystal
Display (LCD)
Display Size 17-in. (43 cm) diagonal and
viewable image
Type TFT liquid crystal display
Input Signal Video 0.7 Vp-p analog RGB
Synchronization Separated H/V (TTL level)
Interface Input Connector 15-pin D-SUB (Analog)
Scanning
Frequency
Horizontal 30–83 kHz
Vertical 56–76 Hz
Max. Resolution
(H x V)
1280 x 1024 @ 75 Hz
Recommended
Resolution
(H x V)
1280 x 1024 @ 60 Hz
Power Source AC/DC Adapter Input Rating:
100–240 V , 2 A max
Output Rating:
12 V , 3.75 A
Frequency: 50/60 Hz
Power Consumption: Less than
50 W in operating mode
Operating
Environment
Temperature 10° C to 35° C
Humidity 20% RH through 80% RH
(without condensation)
Storage
Environment
Temperature –10° C to 60° C
Humidity 5% RH through 90% RH
(without condensation)
Dimensions W x D x H
With standard stand: 404 x 274 x 482 mm
(15.91 x 10.79 x 18.98 in.)
Weight With standard stand: 7 Kg (15.43 lbs)
