Remove the display assembly:
1. Disconnect the display panel cable (1) from the system board.
2. Release the wireless antenna cables (2) from the clips and the opening in the base enclosure.
CAUTION: Support the display assembly when removing the following screws. Failure to
support the display assembly can result in damage to the display assembly and other
computer components.
3. Remove the three Phillips PM2.5×6.0 screws (3) that secure the display assembly to the computer.
4. Remove the display assembly (4).
94 Chapter 4 Removal and replacement procedures
