Item Component Spare part number
(20) RTC battery (includes cable and double-sided tape) 637193-001
(21) Hard drive (2.5-in, 7.0-mm, SATA, does not include hard drive connector cable, isolators, or shield):
For use with all computer models:
750-GB, 5400-rpm 644351-001
640-GB, 5400-rpm 637312-001
500-GB, 7200-rpm 644685-001
320-GB, 7200-rpm 645089-001
320-GB, 5400-rpm 645086-001
250-GB, 7200-rpm 645091-001
Hard Drive Hardware Kit (not illustrated, includes front and rear isolators
and shield)
639444-001
(22) Memory modules (2, DDR3, 10600, 1333-MHz):
4 GB 621569-001
2 GB 621565-001
1 GB 639736-001
(23) Optical drive (includes bezel and bracket):
Blu-ray ROM with LightScribe DVD±R/RW Super Multi Double-Layer Drive 640210-001 and
659878-001
DVD±RW and CD-RW Super Multi Double-Layer Combo Drive with LightScribe 640209-001 and
659877-001
Optical drive bay space saver (not illustrated) 659617-001
(24) WLAN module:
For use on all computer models:
Broadcom 4313 802.11b/g/n 1×1 WiFi and 2070 Bluetooth 2.1+EDR Combo
adapter (BT3.0+HS ready)
600370-001
Ralink 5390GN 802.11b/g/n 1×1 WiFi Adapter 630703-001
Ralink RT3090BC4 802.11b/g/n 1×1 WiFi and Bluetooth 2.1+EDR Combo Adapter
(BT3.0+HS ready)
630705-001
For use only with computer models equipped with an AMD processor:
Atheros 9285G 802.11b/g/n 1×1 WiFi Adapter 605560-005
Atheros AR8002WB-1NGB 802.11b/g/n 1×1 WiFi and Bluetooth 2.1+EDR Combo
Adapter (BT3.0+HS ready)
593127-001
Broadcom 4313 802.11b/g/n 1×1 WiFi Adapter 593836-001
Broadcom 4313GN 802.11b/g/n 1×1 WiFi and 20702 Bluetooth 4.0 Combo
Adapter
657325-001
26 Chapter 3 Illustrated parts catalog
