Spare part number Description
645091-001 250-GB, 7200-rpm hard drive (2.5-in, 7.0-mm, SATA, does not include hard drive connector
cable, isolators, or shield)
647626-001 System board for use only with computer models equipped with the AMD RS880MD chipset, an
AMD processor, and a graphics subsystem with 512-MB of discrete video memory (includes
replacement thermal material)
647627-001 System board for use only with computer models equipped with the AMD RS880MD chipset, an
AMD processor, and a graphics subsystem with 1024-MB of discrete video memory (includes
replacement thermal material)
647630-001 Keyboard in silver finish for use in the United States (includes keyboard cable)
647630-031 Keyboard in silver finish for use in the United Kingdom and Singapore (includes keyboard cable)
647630-041 Keyboard in silver finish for use in Germany (includes keyboard cable)
647630-051 Keyboard in silver finish for use in France (includes keyboard cable)
647630-061 Keyboard in silver finish for use in Italy (includes keyboard cable)
647630-071 Keyboard in silver finish for use in Spain (includes keyboard cable)
647630-121 Keyboard in silver finish for use in Canada (includes keyboard cable)
647630-131 Keyboard in silver finish for use in Portugal (includes keyboard cable)
647630-141 Keyboard in silver finish for use in Turkey (includes keyboard cable)
647630-171 Keyboard in silver finish for use in Saudi Arabia (includes keyboard cable)
647630-211 Keyboard in silver finish for use in Hungary (includes keyboard cable)
647630-221 Keyboard in silver finish for use in the Czech Republic (includes keyboard cable)
647630-251 Keyboard in silver finish for use in Russia (includes keyboard cable)
647630-261 Keyboard in silver finish for use in Bulgaria (for use only with computer models equipped with an
AMD processor; includes keyboard cable)
647630-A41 Keyboard in silver finish for use in Belgium (includes keyboard cable)
647630-B31 Keyboard in silver finish for use in the Netherlands (includes keyboard cable)
647630-BA1 Keyboard in silver finish for use in Slovenia (includes keyboard cable)
647630-BB1 Keyboard in silver finish for use in Israel (includes keyboard cable)
647630-BG1 Keyboard in silver finish for use in Switzerland (includes keyboard cable)
647630-DH1 Keyboard in silver finish for use in Denmark, Finland, and Norway (includes keyboard cable)
647630-DJ1 Keyboard in silver finish for use in Greece (includes keyboard cable)
647630-FL1 Keyboard in silver finish for use in the Slovakia (for use only with computer models equipped with
an Intel processor; includes keyboard cable)
649948-001 System board for use only with computer models equipped with the AMD A60M chipset, an
AMD processor, and a graphics subsystem with UMA video memory (includes replacement
thermal material)
38 Chapter 3 Illustrated parts catalog

HP Pavilion g7 Specifications

General

Bus type	DMI
Stepping	Q0
Tjunction	85 °C
Processor cache	2 MB
Processor cores	2
Processor model	B960
System bus rate	5 GT/s
Processor family	Intel® Pentium®
Processor series	Intel Pentium B900 Series for Mobile
Processor socket	Socket 988
Processor codename	Sandy Bridge
Processor frequency	2.2 GHz
Processor cache type	L3
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	22
Maximum number of PCI Express lanes	16
Motherboard chipset	-
Memory slots	2x SO-DIMM
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	6 GB
Memory layout (slots x size)	1 x 4 GB
AC adapter included	Yes
HDD size	2.5 \
HDD speed	5400 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi DL
Total storage capacity	500 GB
Compatible memory cards	MMC, SD, SDHC
Number of HDDs installed	1
Display surface	Gloss
Display diagonal	17.3 \
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Audio system	HD
Speakers manufacturer	Altec Lansing
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Pointing device	Touchpad
Operating system installed	FreeDOS
Form factor	Clamshell
Product type	Laptop
Product color	Charcoal, Grey
Country of origin	China
Battery life (max)	- h
Number of battery cells	6
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.5 A
AC adapter output voltage	18.5 V
Cables included	AC
Package depth	345 mm
Package width	565 mm
Package height	80 mm
Package weight	4260 g
Operating altitude	-15 - 3048 m
Non-operating altitude	-15 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Processor code	SR07V
Processor ARK ID	59836
Processor package size	37.5x37.5 (rPGA988B) mm
Supported instruction sets	SSE4.1, SSE4.2

Weight and Dimensions

Depth	268 mm
Width	412 mm
Height	36.7 mm
Weight	3000 g
