Item Description Spare part number
(7b) Memory module compartment cover (includes 2 captive screws, secured by C-clips)
(7c) WLAN module compartment cover (includes 1 captive screw, secured by a C-clip)
(7d) Hard drive cover (includes one rubber foot and 2 captive screws, secured by C-clips)
(7e) Display connector cover (includes 1 captive screw, secured by a C-clip)
(8a)
Power switch assembly (includes power switch board cable and power switch
board actuator)
441142-001
(8b) Power switch board actuator
(9a)
Pen eject assembly (includes pen holder) 464113-001
(9b) Pen holder
(10)
System board (includes replacement thermal material) 480850-001
(11) Processor (includes replacement thermal paste)
AMD Turion 64 Mobile Technology ZM-86 (2.4-GHz, 1-MB L2 cache, 800-MHz
FSB)
507974-001
AMD Turion 64 Mobile Technology ZM-84 (2.3-GHz, 1-MB L2 cache, 800-MHz
FSB)
507957-001
AMD Turion 64 Mobile Technology ZM-82 (2.2-GHz, 1-MB L2 cache, 800-MHz
FSB)
507973-001
AMD Turion 64 Mobile Technology ZM-80 (2.1-GHz, 1-MB L2 cache, 800-MHz
FSB)
507972-001
AMD Turion 64 Mobile Technology RM-72 (2.1-GHz, 1-MB L2 cache, 800-MHz
FSB)
507978-001
AMD Turion 64 Mobile Technology RM-70 (2.0-GHz, 1-MB L2 cache, 800-MHz
FSB)
507977-001
AMD Athlon QL-62 (2.0-GHz, 512-KB L2 cache, 667-MHz FSB) 506052-001
AMD Athlon QL-60 (1.9-GHz, 512-KB L2 cache, 667-MHz FSB) 507982-001
(12) Audio/infrared board (includes audio/infrared board cable) 441144-001
(13) Fan/heat sink assembly (includes replacement thermal paste and thermal pads) 487925-001
(14) Pen 464146-001
(15) Optical drive (includes bezel)
DVD±RW and CD-RW SuperMulti Double-Layer Combo Drive with LightScribe 480864-001
DVD±RW and CD-RW SuperMulti Double-Layer Combo Drive 480865-001
(16) Base enclosure (includes optical drive release assembly, 2 battery release latches,
and 4 rubber feet)
466437-001
Rubber Feet Kit (not illustrated, includes base enclosure rubber feet) 464821-001
(17) Memory module (1-DIMM, PC2-6400, 667-MHz, 800 DDR)
2048-MB 480861-001
1024-MB 480860-001
512-MB 480859-001
18 Chapter 3 Illustrated parts catalog
