Item Description Spare part number
(1) Display panel
39.6-cm (15.6-inch) HD, anti-glare, without webcam 683481-001
39.6-cm (15.6-inch) HD, anti-glare, with webcam 683482-001
39.6-cm (15.6-inch) HD, anti-glare, with webcam and WWAN 683483-001
(2) Keyboard (includes cable)
NOTE: For a detailed list of available keyboards, see
Sequential part number listing
on page 41.
For use in models without Windows 8 683491-xxx
For use in models with Windows 8 702237-xxx
(3) Top cover (includes touchpad assembly and cable)
With a fingerprint reader 683506-001
Without a fingerprint reader 683507-001
(4) Audio board 683475-001
(5) Function board/Power button board assembly (includes cable) 683486-001
(6) Speaker assembly 683505-001
(7) RTC battery 683502-001
(8) System board (includes replacement thermal material)
For use in models in which the processor is NOT soldered to the system board; without
Windows 8:
● UMA graphics with WWAN 683496-001
●
UMA graphics without WWAN 683495-001
●
1-GB discrete graphics memory 683493-001
● 2-GB discrete graphics memory 683494-001
For use in models in which the processor is NOT soldered to the system board; with
Windows 8:
●
Windows 8 Standard and UMA graphics with WWAN 683496-501
●
Windows 8 Professional and UMA graphics with WWAN 683496-601
● Windows 8 Standard and UMA graphics without WWAN 683495-501
●
Windows 8 Professional and UMA graphics without WWAN 683495-601
●
Windows 8 Standard and 1-GB discrete graphics memory 683493-501
● Windows 8 Professional and 1-GB discrete graphics memory 683493-601
●
Windows 8 Standard and 2-GB discrete graphics memory 683494-501
●
Windows 8 Professional and 2-GB discrete graphics memory 683494-601
For use in models in which the processor is soldered to the system board:
●
Non-Windows 8 models with UMA graphics and an Intel Core i3-3120M processor 712922-001
Computer major components 27
