Bluetooth module
Description Spare part number
Bluetooth module
NOTE: The Bluetooth module spare part kit does not include a Bluetooth module cable. The
Bluetooth module cable is included in the Cable Kit, spare part number 610806-001. See Cable Kit
on page 27) for more Cable Kit spare part information.
537921-001
Before removing the Bluetooth module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 40).
5. Remove the following components:
a. Switch cover (see
Switch cover on page 51)
b. Keyboard (see
Keyboard on page 53)
c. Top cover (see
Top cover on page 56)
Remove the Bluetooth module:
1. Position the computer right-side up with the front toward you.
2. Remove the Bluetooth module from the base enclosure (1).
3. Disconnect the Bluetooth module cable (2), and then remove the Bluetooth module.
Component replacement procedures 67
